About the Spindle Shaper & Overhead Router
The spindle shaper is the profiling machine of the solid wood shop: rebates, grooves, tongue and groove, mouldings and shaped edges all come off the same 4 kW spindle. Choose a fixed spindle for straight profiling, a tilting spindle for compound profiles, or the H variant with a 1150 mm sliding table for safe cross-grain shaping of frame parts.
The MX-508A overhead router handles template and pattern work — cut-outs, recesses, hardware pockets and shaped components against a pin and template — at spindle speeds up to 18000 rpm.
Key features
- 4 kW (5 HP) spindle motor across the range
- Spindle speeds from 3000 to 10000 rpm depending on model
- Tilting spindle models cover −5° to +45°
- Sliding table of 1150 × 300 mm with 1070 mm stroke on H models
- Overhead router with 800 × 980 mm table and 900 mm throat
Technical specifications
| Parameter | MX-5118 | MX-5118H | MXQ-5118 | MXQ-5118H |
|---|---|---|---|---|
| Spindle diameter | 19 mm (3/4") | 25.4 mm (1") | 30 mm (1-1/4") | — |
| Spindle speed | 3000 r/min | 4500 r/min | 7500 r/min | 10000 r/min |
| Spindle motor | 4 kW (5 HP) | 4 kW (5 HP) | 4 kW (5 HP) | 4 kW (5 HP) |
| Spindle stroke | 130 mm | 130 mm | 130 mm | 130 mm |
| Tilting angle | — | — | −5° ~ 90° ~ +45° | −50° ~ 90° ~ +45° |
| Table size (L × W) | 1150 × 850 mm | 1150 × 850 mm | 1150 × 850 mm | 1150 × 850 mm |
| Sliding table size | — | 1150 × 300 mm | — | 1150 × 300 mm |
| Net weight | 880 kg | 940 kg | 880 kg | 940 kg |
| Parameter | MX-508A |
|---|---|
| Max. thickness of workpiece | 150 mm |
| Working table size (L × W) | 800 × 980 mm |
| Diameter of arbor | 6.3 / 12.7 mm |
| Spindle speed | 9000 / 18000 r/min |
| Motor power | 2.4 / 3 kW |
| Throat | 900 mm |
| Overall dimensions | 1440 × 800 × 1600 mm |
| Net weight | 650 kg |
Design and specifications are subject to change without prior notice.
Typical applications
- Door and window frame profiles
- Mouldings and beadings
- Tongue and groove joints
- Template routing and cut-outs
